MGV PRODUCTS Psychrometric Chart in IP Units, -20 F to 125 F, 11" x 17", Laminated, Crystal Clear, Distinct Colored Lines For Easy Reading (Matt Lamination)
Product details
| Management number | 221559711 | Release Date | 2026/05/03 | List Price | $8.00 | Model Number | 221559711 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Altitude : Sea Level , Atmospheric Pressure : 14.7 PSIA , Temperature Range : -20 F to 125 F , Humidity Ratio Range : 0 to 180 grains of moisture / lb. of dry air.
- Crystal clear, distinct colored lines, nicely numbered, increment mentioned for easy reading.
- Added 35%, 45% and 55% relative humidity curves for accurate calculation to achieve desirable relative humidity.
- Enthalpy and wet bulb temperature doesn’t overlap resulting in less confusion and faster calculation.
- One stop for psychrometric chart as it has all properties ( DBT, WBT, DPT, RH, Enthalpy, HR in grains and lbs, VP) needed for calculation.
- More values on semicircle for sensible heat ratio (SHR) and enthalpy humidity ratio.
- Useful formulas on the back page.
- Printed on 11" x 17" presentation paper and laminated with 10 mils thick glossy finish 12” x 18” lamination pouch for rigidity against bending.
- Easy to write on, plot the points, draw lines on the chart with a pencil (on matt finish) or with dry erase marker (on glossy finish) and erase them when needed.
- Comes with a protective cover to protect the chart from surface scratches.
| Size | 18"L x 12"W |
|---|---|
| Color | Muitlcolor |
| Theme | EDUCATIONAL |
| Pattern | Printed |
| Material | Matt Lamination |
| Is Framed | No |
| Room Type | Classroom, Home Office |
| Brand Name | MGV PRODUCTS |
| Frame Type | Unframed |
| Item Shape | Rectangular |
| Paint Type | Watercolor |
| Unit Count | 1.0 Count |
| Finish Type | Matte |
| Item Weight | 11 Ounces |
| Orientation | Landscape |
| Manufacturer | MGV PRODUCTS |
| Paper Finish | Glossy |
| Mounting Type | Wall Mount |
| Wall Art Form | Art Print |
| Cover Material | Polyvinyl Chloride (PVC) or Plastic |
| Frame Material | Frameless |
| Number of Items | 1 |
| Is Original Artwork | No |
| Indoor Outdoor Usage | Indoor |
| Age Range Description | Adult |
| Item Dimensions L x W | 18"L x 12"W |
